Nichrome wire mesh has bears the acid and alkali,against leakage ability strongly,the easy curl,the cost low status.Widely uses in the battery profession,the manufacture nickel cadmium,the nickel battery,the carp iron electron battery.
The resistance alloy is composed of nickel-chromium alloy, which has high resistivity, good oxidation resistance and very stability. The maximum applicable temperature is up to 1200 degrees, and it has a longer service life than iron, chromium and aluminum.The alloy is widely used in household components, industrial furnaces and various resistance components, such as wirewound resistors, sheet metal resistors, hair dryers, electric furnaces, iron smelting, ovens.
The wire mesh disc diameter is 5490mm. Material: Nichrome wire NiCr80-20. Open size: 15x30mm, wire diameter 1.2mm.
Mechanical and Physical Properties of Alloys
| Grade | NiCr8020 | Ni60Cr15 | Ni35Cr20 | Ni30Cr20 | Ni70Cr30 |
| density（g/cm3) | 8.4 | 8.2 | 7.9 | 7.9 | 8.2 |
| Resistivity(Ωmm2/m) | 1.09 | 1.12 | 1.04 | 1.04 | 1.18 |
| Thermal Conductivity(Wmk) | 15 | 13 | 13 | 13 | 14 |
| Max temp(℃) | 1200 | 1150 | 1100 | 1100 | 1250 |
| Melting temp(℃) | 1400 | 1390 | 1390 | 1390 | 1380 |
| Magnetic | no | no | no | no | no |
| Yield Strength(Mpa) | 420 | 370 | 340 | 340 | 430 |
| Tensile strength(Map) ≥ | 650 | 600 | 600 | 600 | 650 |
| Elongation(%) ≥ | 20 | 20 | 20 | 20 | 20 |
